| Image Sensor |
1/2.7″ CMOS |
| Max. Resolution |
3200 (H) × 1800 (V) |
| ROM / RAM |
128 MB / 256 MB |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
Auto/Manual 1/3 s–1/100,000 s |
| Min. Illumination |
0.007 lux@F1.6 (Color, 30 IRE); 0.0007 lux@F1.6 (B/W, 30 IRE); 0 lux (Illuminator on) |
| S/N Ratio |
>56 dB |
| Illumination Distance |
IR: Up to 30 m | Warm Light: Up to 30 m |
| Illuminator Control |
Auto / Manual |
| Illuminator Number |
1 (Multi-core IR + Warm Light) |
| Angle Adjustment |
Pan: 0°–360° | Tilt: 0°–90° | Rotation: 0°–360° |
| Lens Type / Mount |
Fixed-focal / M12 |
| Focal Length |
2.8 mm; 3.6 mm |
| Max. Aperture |
F1.6 |
| Field of View |
2.8mm: H:110° V:58° D:132° | 3.6mm: H:91° V:46° D:110° |
| Close Focus Distance |
2.8 mm: 1.1 m | 3.6 mm: 1.7 m |
| Human Detection |
Supports classification and accurate detection of humans |
| Smart Search |
Works with Smart NVR for refined search and event extraction |
| Video Compression |
H.265; H.264; MJPEG (Sub stream only) |
| Smart Codec |
Smart H.265+ / Smart H.264+ |
| Frame Rate |
Main stream: 3200×1800@1–20fps / 2688×1520@25/30fps | Sub stream: 704×576@25fps / 704×480@30fps |
| Streams |
2 streams |
| Resolutions |
6M, 4M, 3M, 1080P, 1.3M, 720P, D1, VGA, CIF |
| Bit Rate Control |
VBR / CBR |
| Video Bit Rate |
H.264: 32–8192 kbps | H.265: 12–8192 kbps |
| Day/Night Mode |
Auto (ICR) / Color / B/W |
| BLC / HLC / WDR |
Supported / Supported / DWDR |
| White Balance |
Auto / Natural / Outdoor / Manual / Regional Custom |
| Gain Control |
Auto / Manual |
| Noise Reduction |
3D NR |
| Motion Detection |
ON/OFF (4 areas) |
| Region of Interest (RoI) |
4 areas |
| Smart Illumination / Dual Light |
Supported |
| Image Rotation |
0°/90°/180°/270° (Supports 90°/270° up to 2688×1520) |
| Mirror / Privacy Masking |
Supported / 4 areas |
| Built-in Mic |
Yes |
| Audio Compression |
G.711a, G.711Mu, PCM, G.726 |
| Alarm Events |
Network disconnection, IP conflict, illegal access, motion, tampering, audio detection, SMD (human), security exception |
| Network Port |
RJ-45 (10/100 Base-T) |
| Network Protocols |
IPv4/IPv6, HTTP, TCP, UDP, RTP, RTSP, SMTP, FTP, DHCP, DNS, DDNS, NTP, P2P, etc. |
| Interoperability |
ONVIF (Profile S & T), CGI |
| Users / Bandwidth |
20 users / 48 Mbps |
| Storage |
FTP |
| Browser Support |
IE, Chrome, Firefox |
| Software / Apps |
Smart PSS Lite, DSS, DMSS, DoLynk Care |
| Mobile Support |
iOS / Android |
| Cyber Security |
Video/config encryption, WSSE, HTTPS, X.509 certs, trusted boot/execution/upgrade |
| Certifications |
CE-LVD: EN62368-1 | CE-EMC: Directive 2014/30/EU |
| Power Supply |
12 VDC / PoE (802.3af) |
| Power Consumption |
Basic: 2W (12VDC), 2.9W (PoE); Max: 4W (12VDC), 5.3W (PoE) |
| Operating Temperature |
–40 °C to +60 °C |
| Operating Humidity |
≤95% (non-condensing) |
| Protection |
IP67 |
| Casing Material |
Metal |
| Product Dimensions |
173.3 × 70.0 × 70.0 mm (6.82″ × 2.76″ × 2.76″) |
| Net / Gross Weight |
0.44 kg / 0.55 kg |
