Description
Grandstream GWN7801 | 8-Port Gigabit Layer 2 Managed Switch
Product Overview
The Grandstream GWN7801 is a high-performance Layer 2 managed network switch designed for businesses that
require fast connectivity, strong security, and reliable management capabilities. Equipped with Gigabit ports,
advanced QoS, IPv6/IPv4 support, and cloud or on-premise management, it delivers a flexible and secure solution
for modern enterprise networks.
Key Features
- High-Performance Connectivity: 8× Gigabit Ethernet ports + 2× Gigabit SFP uplink ports for fast and stable networking.
- Dual Stack Support: Fully supports both IPv6 and IPv4 environments for future-proof deployment.
- Enhanced Security: ARP Inspection, IP Source Guard, DoS Protection, and other enterprise-grade safeguards.
- Advanced Traffic Management: VLAN, QoS prioritization, and IGMP Snooping ensure optimized network traffic.
- Flexible Management: Manage via Local Web UI, GWN.Cloud, or GWN Manager for simple scaling and remote control.
Technical Specifications
| Category | Specification |
| Model | Grandstream GWN7801 |
| Ports | 8× Gigabit RJ45 Ports 2× Gigabit SFP Uplink Ports |
| Network Standards | IEEE 802.3, 802.3u, 802.3ab, 802.3x, 802.1Q, 802.1p, 802.1D, 802.1w |
| Layer 2 Features | VLAN (IEEE 802.1Q), Voice VLAN IGMP Snooping v1/v2/v3 Link Aggregation (LAG) Spanning Tree Protocol |
| Traffic Management | Quality of Service (QoS) Rate Limiting Storm Control |
| Security Features | ARP Inspection IP Source Guard DoS Protection 802.1X Port-Based Authentication |
| Management Options | Local Web UI GWN.Cloud GWN Manager (On-Premise) |
| Dual Stack Support | IPv4 / IPv6 |
| Switching Capacity | 20 Gbps |
| Forwarding Rate | 14.88 Mpps |
| Power | External Power Adapter |
| Operating Temperature | 0°C to 50°C |
| Dimensions | 230 × 150 × 44 mm |
The Grandstream GWN7801 is ideal for businesses seeking a high-performance, secure, and easy-to-manage
networking solution.
