| Display |
2.8″ TFT Color LCD Screen (320×240) |
| Camera |
N/A |
| Operating System |
Linux |
| Hardware |
CPU: Dual Core@1GHz; RAM: 512MB; ROM: 8GB; Speaker: 8Ω@1W; Physical Keypad: 16 Keys; Fingerprint Sensor: ZK Optical Sensor; Casing: Black & White |
| Authentication Method |
Fingerprint / Card / Password (Physical Keypad) |
| Fingerprint Capacity |
3,000 (1:N) (Standard) |
| Face Capacity |
N/A |
| Card Capacity |
3,000 (1:N) (Standard) |
| User Capacity |
3,000 (1:N) (Standard) |
| Transaction Capacity |
150,000 (1:N) |
| Max. User Password Length |
8 Digits |
| Biometric Authentication Speed |
Less than 1 sec (Fingerprint) |
| Touchless Biometric Recognition Distance |
/ |
| False Acceptance Rate (FAR) |
≤ 0.0001% (Fingerprint) |
| False Rejection Rate (FRR) |
≤ 0.1% (Fingerprint) |
| Biometric Algorithm |
ZKFingerprint V13.0 (Standard) / V10.0 (Optional) |
| Card Type |
ID Card@125 kHz (Standard), IC Card@13.56 MHz (Optional) |
| Standard Functions |
ADMS, DST, Photo Capture, Event Photo Capture, Up to 14-digit User ID, Record Query, Schedule Bell, Tamper Switch Alarm, Automatic Status Switch, Multiple Authentication Methods, HTTPS / SSH Backend Access, T9 Keyboard |
| Optional Functions |
IC Card, Wi-Fi, Backup Battery |
| Power Supply |
DC 12V 3A |
| Backup Battery (Optional) |
2,000 mAh (Lithium Battery); Max Operating: 4h; Standby: 7h; Charging Time: 5h |
| Operating Temperature |
-5°C to 45°C |
| Operating Humidity |
10% to 90% RH (Non-condensing) |
| Dimensions (L×W×H) |
154 mm × 138 mm × 34 mm |
| Gross Weight |
0.99 kg |
| Supported Software |
ZKBio Zlink (Mobile & Cloud), ZKBio Time (On-Premise) |
| Installation |
Wall-mount (Compatible with Asian Gang Box / Single Gang Box) |
| Certifications |
ISO14001, ISO9001, CE, FCC, RoHS |
