Description

SenseFace 7 A & SenseFace 7B Specifications

Parameters	Details
Model	SenseFace 7A / SenseFace 7B
Display	7″ TFT Color Touch LED Screen (600×1024)
Camera	WDR Binocular Camera @ 1MP
Operation System	Linux
Hardware	CPU: Dual Core @1GHz RAM: 512MB; ROM: 8GB Speaker: 8ohm @1W Microphone: *1 (Sensitivity: -32dB / Omni-directional / SNR: -32dB / Impedance: 2.2kΩ) Supplement Light: No Fingerprint Sensor: In-Glass Fingerprint (Z-ID) (SenseFace 7A / SenseFace 7A (Big Capacity Version))
Authentication Method	SenseFace 7A: Fingerprint / Face / Card / Password (Virtual Keypad) SenseFace 7B: Face / Card / Password (Virtual Keypad) SenseFace 7A (Big Capacity Version): Fingerprint / Face / Card / Password (Virtual Keypad) SenseFace 7B (Big Capacity Version): Face / Card / Password (Virtual Keypad)
Fingerprint Template Capacity	SenseFace 7A: 10,000 (1:N) SenseFace 7B: / SenseFace 7A (Big Capacity Version): 50,000 (1:N) SenseFace 7B (Big Capacity Version): /
Face Template Capacity	SenseFace 7A / 7B: 10,000 (1:N) SenseFace 7A / 7B (Big Capacity Version): 50,000 (1:N)
Card Capacity	50,000 (1:N) (Standard)
User Capacity	50,000 (1:N) (Standard)
Transaction Capacity	300,000
Max. User Password Length	8 Digits
Biometric Verification Speed	SenseFace 7A / 7A (Big Capacity): <0.5 sec (Fingerprint); <0.35 sec (Facial) SenseFace 7B / 7B (Big Capacity): <0.35 sec (Facial)
Touchless Biometric Recognition Distance	30cm to 200cm (Facial Authentication)
False Acceptance Rate (FAR)	SenseFace 7A / 7A (Big Capacity): ≤0.01% (Face); ≤0.0001% (Fingerprint) SenseFace 7B / 7B (Big Capacity): ≤0.01% (Face)
False Rejection Rate (FRR)	SenseFace 7A / 7A (Big Capacity): ≤0.02% (Face); ≤0.01% (Fingerprint) SenseFace 7B / 7B (Big Capacity): ≤0.02% (Face)
Biometric Algorithm	SenseFace 7A: ZKFace V4.0; ZKFingerprint V13.0 (Standard) / V10.0 (Optional) SenseFace 7B: ZKFace V4.0 SenseFace 7A (Big Capacity): ZKFace V3.7; ZKFingerprint V13.0 (Standard) / V10.0 (Optional) SenseFace 7B (Big Capacity): ZKFace V3.7
Card Type	ID Card @125 kHz (Standard) IC Card @13.56 MHz (Optional)
Communication	TCP/IP 1 Wi-Fi (IEEE802.11b/g/n/ax) @2.4 GHz (Optional) Wiegand (Input/Output) 1 RS485: ZKTeco RS485 1 USB: Type A (USB Drive Only) 1 Aux Inputs 1, Electric Lock 1, Door Sensor 1, Exit Button 1, 12V Output *1
Standard Functions	ADMS, DST, Photo Capture, Event Photo Capture, Up to 14-digit User ID, Access Levels, Groups, Holidays, Anti-Passback, Record Query, Schedule Bell, Tamper Switch Alarm, Automatic Status Switch, Multiple Authentication Methods, SIP Client (V2.0), ONVIF (Profile S/T/G/C/Q/A), AC Push & TA Push, HTTPS/SSH Backend Access, T9 Keyboard
Optional Functions	IC Card, Wi-Fi, Wireless Doorbell
Access Control Interface	RS485 (Card Reader / Biometric Reader)
Video Intercom	ZKTeco Private Protocol via TCP/IP: Standalone Terminal: SenseFace Series Indoor Monitor: VT07-B01, VT07-B01-WStandard SIP Protocol: Standalone Terminal: SenseFace Series Indoor Monitor: VT07-B22L, VT07-B26L-W Software: ZKBio CVSecurity, BioTalk Pro Mobile App: ZKBio Zlink, ZKBio Zexus
Power Supply	DC 12V 3A (Optional)
Operating Temperature	-5°C to 45°C
Operating Humidity	10% to 90% RH (Non-condensing)
Dimensions	SenseFace 7A / 7A (Big Capacity): 238mm × 115mm × 22.3mm (L×W×H) SenseFace 7B / 7B (Big Capacity): 214mm × 115mm × 22.3mm (L×W×H)
Net Weight	0.622 kg
Ingress Protection Rating	IP65 (Waterproof and Dustproof)
Supported Software	On-Premise: ZKBio CVSecurity (AC PUSH) & ZKBio Time (TA PUSH) Cloud-Based: ZKBio Zlink (Web Portal & Mobile App)
Installation	Wall-mount (Compatible with Asian Gang-box / Single Gang-box)
Certifications	ISO14001, ISO9001, CE, FCC, RoHS
Output Contact	2
